Ceramic Fiber Insulation Board – 2300F Rated – 0.47″ X 12″ X 12″ – Pack of 1 – Fireproof Insulation Board for Wood Stoves, Pizza Ovens, Forges, Kilns, Furnaces, Fireplaces
$22.99 $33.99
- Aluminosilicate Refractory Ceramic Fiber Board measures 0.47” x 12” x 12” in size
- Maximum Use Temperature: This fireproof board has high heat resistance and can withstand temperatures up to 2300F (1260 C) | Density: 20-24 lb/ft³ This ceramic board has high compressive strength at 25% deformation – 78 PSI, Permanent Linear Shrinkage – 3.5% Max at 2200F when exposed to 24 hours soaking heat, Loss of Ignition (LOI) at 1832F: 4-7%
- Easy to cut: This fireboard can be easily cut with a knife and hacksaw blade and can be drilled and machined. This fiber board is not as strong as fire brick, it dents easily
- Versatile Uses: High temperature board is used to repair or build, Wood Stove, Fireplaces, Pizza Ovens, Kiln, Forges, Internal Baffle of Wood Stove, Pellet Stoves, Backup Insulation of Refractory Bricks and Castable Linings, Furnace Hot Face Linings and Boiler Wall Insulation, heat shields, combustion chambers, fire protection. Commonly used to make target walls, front plates, and floor insulation
Only 5 left in stock - order soon.
Description
Available in Various Sizes
Product Specifications
| Classification Temperature (F) | 2300 |
| Colour | White/Tan |
| Density (Lbs/ft3)/td> | 20 – 24 |
| Size (T x W x L) | 1/2 inch x 19.7 inch x 39.4 inch |
| Thickness Tolerance | – 0.04 inch, + 0.08 inch |
| Width Tolerance | ± 0.12 inch |
| Length Tolerance | -0.12 inch, +0.2 inch |
| Hardness (Shore A) | 50 Minimum |
| Moisture (%) | 10 Maximum |
| Modulus of Rapture (Kpa) | 980 Minimum – For 1” Thick; 588 Minimum – For 2” Thick |
| Permanent Linear Shrinkage (%) | 3.5 Maximum (After 24 Hrs. shocking Heat at 2200°F) |
| Compressive Strength (Kpa) | 274.6 Minimum (10% deformation for 1” Thick) |
| Compressive Strength (Kpa) | 539.4 Minimum (25% deformation for 1” Thick) |
| Al2O3 (%) | 44-45 |
| SiO2 (%) | 55-58 |
| LOI % at 1832°F | 4 – 7 |
Key Product Features
Ceramic Fiber Insulation Board is ideal for use in Wood Stoves, Fireplaces, Pizza Ovens, Kilns, Forges, Internal Baffle of Wood Stove, Pellet Stoves, Backup Insulation of Refractory Bricks, and Castable Linings, Furnace Hot Face Linings and Boiler Wall Insulation, Heat shields, Combustion Chambers and fire protection.
Wide Applications
Ceramic Fiber Insulation Board is ideal for use in Wood Stoves, Fireplaces, Pizza Ovens, Kilns, Forges, Internal Baffle of Wood Stove, Pellet Stoves, Backup Insulation of Refractory Bricks, and Castable Linings, Furnace Hot Face Linings and Boiler Wall Insulation, Heat shields, Combustion Chambers and fire protection.
|
|
|
|
|
|
|
|---|---|---|---|---|---|---|
| Ceramic Fiber Insulation Board, (2300F) (0.5″ x 19.7″ x 39.4″) – Pack of 1 | Ceramic Fiber Insulation Board, (2300F) (0.47″ x 12″ x 24″) – Pack of 1 | Ceramic Fiber Insulation Board, (2300F) (0.47″ x 18″ x 24″)- Pack of 1 | Ceramic Fiber Insulation Board, (2300F) (1″ x 12″ x 12″) – Pack of 1 | Ceramic Fiber Insulation Board, (2300F) (1″ x 12″ x 24″) – Pack of 1 | Ceramic Fiber Insulation Board, (2300F) (0.5″ x 23.6″ x 23.6″) – Pack of 1 | |
| Temperature Grade (F) | 2300 | 2300 | 2300 | 2300 | 2300 | 2300 |
| Density (lbs/ft3) | 20-24 | 20-24 | 20-24 | 20-24 | 20-24 | 20-24 |
| Size (T x W x L) | 0.5″ x 19.7″ x 39.4″ | 0.47″ x 12″ x 24″ | 0.47″ x 18″ x 24″ | 1″ x 12″ x 12″ | 1″ x 12″ x 24″ | 0.5″ x 23.6″ x 23.6″ |
| Qty | 1 | 1 | 1 | 1 | 1 | 1 |
Product information
| Product Dimensions | 12 x 12 x 0.47 inches |
| ASIN | B075PCMXL5 |
| Customer Reviews | 4.7 out of 5 stars |
| Best Sellers Rank | #122,652 in Arts, Crafts & Sewing #108 in Firing Accessories |
| Is Discontinued By Manufacturer | No |
| Item Weight | 1.74 pounds |
| Manufacturer | Simond Fibertech Limited |
| Date First Available | September 16, 2017 |
