Blacksmith Welded Coal Forge

Perfect Design

Fabricated Firepot is one of the important tool in a blacksmith’s workshop. It is the Perfect replacement for your cast iron firepot, fixing up an old forge, or building up a new forge with the help of a Hand Crank Blower.
Product Features

Premium Material
This Handmade blacksmith coal forge firepot is made of a ½” Thick Steel Plate and strongly welded inside and out, making it more heavy-duty than the cast iron firepot. So, when exposed to temperature Changes this fabricated firepot does not create any cracking like cast iron.

Large Working Area
Inside of the Coal Forge firepot measures 10” x 12” and has a 4.5" inside depth. it provides a large working area for forging your handmade hammers, punches, tongs, and other metalworking operations. Perfect choice for any blacksmith, metal worker, or aspiring forger.

Stand For Support
Our Welded Blacksmithing Firepot comes with a stand that has an upper and lower supporting plate, four square pipes, and mounting hardware. Blacksmith's Welded Coal Forge when put on this stand provides the perfect height for your desired forging or metalworking operation.

Air Inlet Pipe
Air inlet pipe 3” round (OD) and 4.5” Long, lets the air come into the firepot from the connected hand crank blower, allowing more oxygen to reach the coal at the bottom of the firepot, and let coal fully burn to provide the perfect forging temperature.

Clinker Breaker
The Clinker Breaker on ½ inch rod has a turn-down end that serves as a handle and is rotatable, it is used to easily remove waste ash dump as well as let the air blow in the firepot. It is perfectly fit for the slot in the ash dump.

Auto adjustable Ash dump
This firepot design is featured an auto-adjustable ash dump at the bottom. The weighted ash dump has an auto open-close feature. You don’t need to manually open the weighted ash dump when waste ash dump produces, it opens automatically and also automatically closes.
Wide Application

Product Specification
Material | MS ½ inch thick plate |
Inside Dimension | 10” x 12” x 4.5” |
Fits in Regular Hole | Minimum 10.5” x 12.25” – Maximum 11.75” x 13.75” |
Clinker Breaker | ½ inch thick plate and round handle. |
Weighted Ash Dump | 11” long and 3.5” square cross-section |
Air inlet Pipe | 3” Round (OD) and is 4.5” long |
Inside Depth | 4.5 inch |
Stand Dimension | 15” x 13” x 22” |
